Video Measuring Machine NABL Calibration Services

Name: Video Measuring Machine NABL Calibration Services
Brand: Enviro Instruments
Price: 3000.0 INR
Availability: InStock

3000.0 INR/Unit

Get a Price/Quote

Product Details:

Measuring Range 0-300 mm
Power Supply 220V AC, 50 Hz
Interface Type USB 2.0 / RS232
Resolution 0.001 mm
Temperature 15C - 30C
Response Time <1 second
Operating Voltage 220V AC
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Video Measuring Machine NABL Calibration Services Price And Quantity

Price 3000.0 INR/Unit
Minimum Order Quantity 1 Unit

Video Measuring Machine NABL Calibration Services Product Specifications

Power Supply 220V AC, 50 Hz
Measuring Range 0-300 mm
Resolution 0.001 mm
Interface Type USB 2.0 / RS232
Capacity Up to 50 kg
Operating Voltage 220V AC
Temperature 15C - 30C
Response Time <1 second
Frequency 50 Hz
Specimen Size Custom/As Required
Display Type Digital LCD
Max Height 200 mm
Accuracy (2.5+L/100) m
Number of Specimens Single
Mounting Type Bench Top
Test Speed Up to 200 mm/s
Port Size Standard
Humidity 20% - 80% RH
Automation Grade Semi-Automatic
Control Mode Manual/Automatic
Test Width 300 mm
Machine Weight Approx 250 kg
Test Range 0 - 300 mm
Equipment Type Video Measuring Machine
Usage Calibration & Quality Control
Test Stroke 200 mm
Application Dimension and geometry calibration
Features NABL Traceability, 3-axis measurement, robust construction

Camera Type High-Resolution CCD
Work Table Material Granite
Environmental Conditions Vibration-Free, Dust-Controlled Area Recommended
Stage Travel X: 300mm, Y: 200mm, Z: 200mm
Lens Magnification 0.7x - 4.5x
Image Processing Software Yes, advanced measurement software included
Data Output USB/RS232/Ethernet
Repeatability 2 m
Illumination LED Surface & Contour

Product Description

NABL Calibration of Video Measuring Machine (Angle) L.C.: 1 s, Range: Up to 90/ Video Measuring Machine (Linear) (0-300 mm (X-Axis), 0-200 mm (Y-Axis)) L.C.: 0.0001 mm, Range: 0 to 300 mm

Comprehensive Dimension Calibration

Our calibration service leverages a high-resolution CCD camera and advanced measurement software, delivering unparalleled dimensional accuracy across a 0-300 mm range. Each measurement undergoes thorough analysis under LED illumination, ensuring every contour and surface detail is captured. Hard granite tables and robust positioning stages guarantee stability, making the system suitable for precise quality control applications across industrial sectors. With digital LCD readouts and rapid response times, measurements are delivered promptly and reliably.

Advanced Software and Data Connectivity

Equipped with sophisticated image processing and measurement software, the service provides efficient, repeatable results for even the most complex geometries. Direct data output options including USB, RS232, and Ethernet streamline integration with your data management systems. The digital display offers immediate, high-resolution readings, while automated and manual controls enable adaptability for varied calibration workflows. All measurement results are traceable to NABL standards for audit readiness.

Optimal Operating Environment

To maximize precision, the Video Measuring Machine should operate in a vibration-free, dust-controlled area with temperatures between 15C-30C and relative humidity from 20%-80%. Its robust construction and granite worktable ensure minimal influence from environmental changes. The machine requires a standard 220V AC, 50 Hz supply and fits most benchtop setups, making it accessible for a variety of laboratories and quality control departments.

FAQ's of Video Measuring Machine NABL Calibration Services:

Q: How is the calibration process performed with the Video Measuring Machine?

A: Calibration is carried out by placing the specimen on the granite work table and using the high-resolution CCD camera, advanced measurement software, and LED illumination to capture precise dimensional and geometric data. The procedure ensures traceability to NABL standards throughout each stage.

Q: What benefits does NABL traceable calibration offer for my quality control?

A: NABL traceable calibration guarantees that all measured values adhere to recognized international standards, improving accuracy and boosting confidence in your quality control processes. It is essential for maintaining compliance with regulatory and customer requirements.

Q: When should I consider scheduling NABL calibration services for my equipment?

A: Calibration should be scheduled at regular intervals recommended by industry standards or whenever you observe measurement inconsistencies. Routine recalibration ensures ongoing reliability and accuracy in your measurement tasks.

Q: Where is the optimal location to install and operate this Video Measuring Machine?

A: For best results, install the machine in a vibration-free, dust-controlled room with stable temperatures between 15C-30C and relative humidity between 20%-80%. Such conditions help maintain repeatable accuracy and prolong equipment life.

Q: What is the process for capturing and exporting measurement data?

A: After positioning the specimen and conducting measurements using the advanced software, results are displayed on the digital LCD and can be exported directly via USB, RS232, or Ethernet interfaces for record-keeping and further analysis.

Q: How does the advanced measurement software enhance calibration accuracy?

A: The included software offers automated edge detection, contour analysis, and sophisticated geometric calculations, significantly reducing operator error and improving dimensional analysis precision.

Q: What types of specimens and applications is the service suitable for?

A: This calibration service supports custom specimen sizes up to 50 kg for dimensional and geometry calibration, making it ideal for a wide range of industrial, manufacturing, and quality control applications.
