Hi-Lo Gauge Calibration

Name: Hi-Lo Gauge Calibration
Brand: Enviro Instruments
Price: 2000.0 INR
Availability: InStock

2000.0 INR/Unit

Get a Price/Quote

Product Details:

Max Height 20 mm
Accuracy 0.1 mm
Measuring Range 0-20 mm
Test Range 0-20 mm
Hardness 45-60 HRC
Specimen Size Flat, as per standard pipe/flange thickness
Display Type Analog Vernier Scale
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Hi-Lo Gauge Calibration Price And Quantity

Price 2000.0 INR/Unit
Minimum Order Quantity 1 Unit

Hi-Lo Gauge Calibration Product Specifications

Resolution 0.1 mm
Machine Weight 2.5 Kg
Number of Specimens 1
Max Height 20 mm
Equipment Type Hi-Lo Weld Gauge
Accuracy 0.1 mm
Application Measurement of internal misalignment (Hi-Lo), pipe wall thickness and weld height
Measuring Range 0-20 mm
Test Range 0-20 mm
Automation Grade Manual
Hardness 45-60 HRC
Control Mode Manual
Response Time Instant
Humidity 0-90% Non-condensing
Test Stroke 20 mm
Temperature 0-50 C
Capacity Up to 20 mm gap
Specimen Size Flat, as per standard pipe/flange thickness
Test Speed Manual Operation
Display Type Analog Vernier Scale
Test Width 25 mm
Mounting Type Handheld
Usage Weld and Pipe Measurement
Features Corrosion Resistant, Portable, Replaceable tip

Product Code HLG-01
Material Stainless Steel (Body and Measuring Jaws)
Calibration Method Factory calibrated and adjustable
Case Included Protective Storage Case Provided
Finish Type Satin/Polished

Hi-Lo Gauge Calibration Trade Information

Delivery Time 7 Days

Product Description

Unlock the resplendent precision of the elite Hi-Lo Gauge Calibration (Product Code: HLG-01). Crafted with stainless steel body and measuring jaws, boasting a remarkable satin or polished finish, this portable equipment delivers flawless measurements for weld and pipe applications. Its factory calibration ensures unquestionable accuracy, while the corrosion-resistant design and replaceable tip guarantee lasting performance. Try now and experience instant manual operation through an analog vernier scale, offering a resolution and accuracy of 0.1 mm. Complete with a protective storage case, this gauge is the ultimate choice for discerning professionals.

Elite Calibration for Flawless Hi-Lo Measurement

Hi-Lo Gauge Calibration is used for accurately measuring internal weld misalignment (Hi-Lo), pipe wall thickness, and weld height. Its remarkable precision and robust stainless steel design make it a superior choice for monitoring and inspecting weld quality. Typically used as a manual, handheld device in the field or workshop, the gauge's versatility and resplendent accuracy give your processes a competitive advantage in maintaining industry standards and ensuring consistent results.

Packaging, Sample Policy, and Certifications

Our Hi-Lo Gauge Calibration comes in a secure, protective storage case, ensuring defect-free delivery through all forms of transportation. Each unit is individually packaged with careful attention to prevent any damage. If you wish to estimate suitability before purchase, samples may be provided as per policy. Certifications confirming compliance with industrial measurement standards are included, giving you complete confidence in the authenticity and reliability of every gauge.

FAQ's of Hi-Lo Gauge Calibration:

Q: How is the Hi-Lo Gauge Calibration device used?

A: The Hi-Lo Gauge is manually operated to measure internal misalignment, weld height, and pipe wall thickness. Simply align the jaws on the specimen and observe the readings on the analog vernier scale.

Q: What makes this Hi-Lo Gauge Calibration device remarkable compared to standard options?

A: This gauge stands out due to its stainless steel construction, precise factory calibration, corrosion resistance, instantaneous response, and replaceable tip, all while maintaining a highly portable, manual design.

Q: Where can this Hi-Lo Gauge be applied?

A: It is ideally used in industrial settings, construction sites, workshops, and inspection areas for checking welds and pipe joints according to relevant standards.

Q: What is the process to recalibrate the gauge if needed?

A: The device is factory calibrated but adjustable. Users can follow the provided instructions to fine-tune calibration for optimal accuracy as required.

Q: When should the tip be replaced?

A: Replace the measuring tip when you notice signs of wear or diminished measurement accuracy, ensuring consistently flawless results.

Q: What are the benefits of the included protective storage case?

A: The robust protective storage case shields the gauge from damage during transportation and storage, maintaining its performance and lengthening its lifespan.
